Microprocessor single beam visible spectrophotometer with software

Microprocessor single beam visible spectrophotometer with software

59500 INR/Piece

Get a Price/Quote

Product Details:

Accuracy 0.5% T or better
Control Type Microprocessor-based with keypad
Features Single beam operation, inbuilt calibration, user-friendly software, USB/PC connectivity, data storage, self-diagnostics
Temperature Resistance Ambient laboratory conditions
Shape Rectangular
Glass Type Quartz or optical glass cuvette compatible
Display Type Large graphic LCD display
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Microprocessor single beam visible spectrophotometer with software Price And Quantity

Minimum Order Quantity 1 Piece
Price 59500 INR/Piece

Weight Approx. 8 kg
Interface User-friendly keypad and software interface
Sample Holder 4-position cell holder
Relative Humidity <85% RH (non-condensing)
Spectral Bandwidth 4 nm
Photometric Range 0200%T, -0.33A, 01999C
Operating Temperature 15 40C
Light Source Tungsten Halogen Lamp, 6V 10W
Wavelength Range 320 nm 1000 nm
Detector Silicon Photodiode
Data Output USB, RS232, printer port
Wavelength Accuracy 2 nm
Wavelength Repeatability 1 nm
Software Compatibility Windows-based software for data analysis and storage

Microprocessor single beam visible spectrophotometer with software Product Specifications

Type Microprocessor Single Beam Visible Spectrophotometer
Power 50 W
Accuracy 0.5% T or better
Equipment Type Laboratory Spectrophotometer
Control Type Microprocessor-based with keypad
Usage For Laboratory
Features Single beam operation, inbuilt calibration, user-friendly software, USB/PC connectivity, data storage, self-diagnostics
Material ABS Plastic
Shape Rectangular
Weight 2-5 Kilograms (kg)
Temperature Resistance Ambient laboratory conditions
Equipment Materials High quality ABS plastic and powder-coated metal body
Product Type Spectrophotometer
Dimension (L*W*H) 485 x 390 x 180 mm
Application Quantitative analysis, wavelength scanning, educational labs, chemical analysis
Power Supply AC Mains power
Display Type Large graphic LCD display
Voltage 220V AC 10%, 50 Hz
Glass Type Quartz or optical glass cuvette compatible

Weight Approx. 8 kg
Interface User-friendly keypad and software interface
Sample Holder 4-position cell holder
Relative Humidity <85% RH (non-condensing)
Spectral Bandwidth 4 nm
Photometric Range 0200%T, -0.33A, 01999C
Operating Temperature 15 40C
Light Source Tungsten Halogen Lamp, 6V 10W
Wavelength Range 320 nm 1000 nm
Detector Silicon Photodiode
Data Output USB, RS232, printer port
Wavelength Accuracy 2 nm
Wavelength Repeatability 1 nm
Software Compatibility Windows-based software for data analysis and storage

Microprocessor single beam visible spectrophotometer with software Trade Information

Payment Terms Cash on Delivery (COD), Telegraphic Transfer (T/T), Paypal, Cash in Advance (CID), Cash Advance (CA)
Supply Ability 7 Piece Per Day
Delivery Time 1 Week
Sample Available No
Main Export Market(s) Western Europe, Central America, Africa, Eastern Europe, Middle East, South America, Australia, Asia, North America
Main Domestic Market All India

Product Description

We aredevoted towards offering the qualitative range of MicroprocessorSingle Beam Visible Spectrophotometer, as per clients precise need andrequirements.

Other detail:

This spectrophotometer is available in different models and sizes.
Moreover, it is designed by our skilled professionals by using quality material and advanced technology.

Product Specification

Model Number/Name	Aei-MS-Rt115
Wavelength Range	325-1000 nm
Optical System	Single Beam 1200 lines/mm
Display	LCD Display
Type	Fixed,Non Portable
Application	Laboratory Use
Size	420 X 280 X 180 mm
Band width	2 nm
Data Output Port	USB
Detector	Silicon Photodiode
Dimensions	420 X 280 X 180 mm
Lamps	Tungston Halogen Lamp
Photometric Range	-0.3 to 3.0 Abs
Power Requirement	AC 220V/50Hz.
Brand	AjantaExports
Minimum Order Quantity	1 Unit

Exceptional Accuracy and Repeatability

With a wavelength accuracy of 2 nm and repeatability of 1 nm, this spectrophotometer ensures consistent results for quantitative and chemical analyses. Inbuilt calibration features guarantee precise readings, minimizing user errors and enhancing overall reliability during experiments.

Versatile Data Management

Equipped with multiple connectivity options such as USB, RS232, and a printer port, the device makes data output and storage seamless. The Windows-based software enables comprehensive data analysis as well as easy integration with laboratory information systems, helping users manage and retrieve data efficiently.

Ergonomic Design and User-Friendly Interface

The spectrophotometer boasts a robust yet lightweight structure made from high-quality ABS plastic and powder-coated metal. Its straightforward keypad and large graphic LCD display streamline navigation and operation, making it comfortable for extended laboratory use.

FAQ's of Microprocessor single beam visible spectrophotometer with software:

Q: How does the microprocessor-based control enhance the accuracy of measurements?

A: The microprocessor-based control in this spectrophotometer enables automated calibration and precise control over measurement parameters, leading to consistent and highly accurate results for all your quantitative analyses.

Q: What types of samples and cuvettes can be used with this spectrophotometer?

A: This unit is compatible with both quartz and optical glass cuvettes, making it versatile for a wide range of sample types in visible wavelength experiments. The 4-position cell holder allows efficient processing of multiple samples.

Q: When should I perform instrument calibration, and what is the process?

A: Calibration is recommended before starting each new set of measurements or when accuracy is critical. The instrument features inbuilt calibration routines that can be initiated via the keypad or software interface, ensuring reliable and repeatable results.

Q: Where can data be stored and exported from the spectrophotometer?

A: Data collected can be stored internally, exported via USB or RS232 to external computers, or printed directly using the printer port. The included Windows-compatible software facilitates comprehensive data analysis and storage on PCs.

Q: What applications benefit most from this spectrophotometer?

A: This spectrophotometer is ideal for laboratory quantitative analysis, wavelength scanning, educational demonstrations, and general chemical analysis. Its precision and flexibility are suited for research, industrial, and academic labs alike.

Q: How user-friendly is the software and the instrument interface?

A: Both the software and hardware interfaces are designed to be intuitive. The spectrophotometer features a large graphic LCD display and a user-friendly keypad, while the Windows-based software offers straightforward navigation, data analysis, and storage functions.

Q: What benefits are provided by the device's construction materials and design?

A: Manufactured from durable ABS plastic and powder-coated metal, the device is resilient against chemical exposure and physical wear. Its compact, rectangular shape and manageable weight ensure easy placement and usability in any laboratory environment.
