Whirling of Shaft Apparatus

35000 INR/Piece

Get a Price/Quote

Product Details:

Product Type Shaft Apparatus
Material Stainless Steel
Application For Laboratory
Voltage 220 Volt (v)
Weight 40-80 Kilograms (kg)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Whirling of Shaft Apparatus Price And Quantity

Minimum Order Quantity 1 , Piece
Price 35000 INR/Piece

Whirling of Shaft Apparatus Product Specifications

Weight 40-80 Kilograms (kg)
Application For Laboratory
Voltage 220 Volt (v)
Product Type Shaft Apparatus
Material Stainless Steel

Whirling of Shaft Apparatus Trade Information

Payment Terms Telegraphic Transfer (T/T), Cash in Advance (CID), Cheque, Cash Advance (CA)
Supply Ability 7 , Piece Per Day
Delivery Time 1 Week
Main Export Market(s) Western Europe, Australia, North America, South America, Eastern Europe, Middle East, Central America, Asia, Africa
Main Domestic Market All India

Product Description

With wide expertise in this domain we are engaged in manufacturing and supplying Whirling of Shaft Apparatus. These are precision-engineered by the experts of our firm using superior grade material and advanced instruments. Other specifications of the product are enlisted below:

Scope Of Experimentation:-

Fixed end conditions: Make use of end blocks with double bearing. The guards D1 & D2 can be fixed at any position on the supporting bar frame, which fits on side support F Rotating shafts are to be fitted in blocks in A &B stands
Supported end conditions: Make use of end blocks with single self-aligning bearing

Utilities Required:-

A dimmer state of 240v, 2amp, and 50 cycles is used to control speed of the rotating shaft
The driving motor is 230V DC 1/16
H.P: 6500 RPM

Equipment Details:

The fixing ends provide change of end fixing condition of the rotating shaft as per the requirement
The shaft & the end-fixing device can be replaced within a short time with the help of this unit
Ball bearing fixing ends: The ends fix the shaft while it rotates
Coupling: A flexible shaft is used to drive the test shaft from motor

Key Features

Crafted from robust stainless steel, the Whirling of Shaft Apparatus guarantees longevity and consistent performance. With a weight range of 40 to 80 kilograms, the system offers a stable base for accurate experimental results. Its 220 Volt power configuration makes it compatible with common laboratory electrical standards.

Application in Laboratories

This apparatus is specifically designed for use in laboratories where it facilitates demonstrations and studies related to the principles of shaft dynamics. Students, educators, and researchers benefit from its user-friendly design and reliable construction, enabling in-depth analysis and experimentation.

FAQ's of Whirling of Shaft Apparatus:

Q: How does the Whirling of Shaft Apparatus demonstrate shaft dynamics in a laboratory?

A: The apparatus allows users to simulate and observe the behavior of a rotating shaft under different speeds, helping them study phenomena such as critical speed, modes of vibration, and shaft instability in a controlled environment.

Q: What materials are used in the construction of this apparatus and why?

A: This apparatus is built entirely from stainless steel, which is chosen for its high strength, durability, and resistance to corrosion, ensuring a long lifespan even with repeated use in laboratory settings.

Q: When is this apparatus typically used in educational or research laboratories?

A: It is commonly employed during courses or experiments related to mechanical engineering, dynamics of machinery, and vibration analysis, especially when teaching or researching topics involving rotating machinery.

Q: Where can I purchase or obtain the Whirling of Shaft Apparatus in India?

A: The Whirling of Shaft Apparatus is available through various distributors, exporters, manufacturers, suppliers, and traders across India. You can contact these vendors directly or visit their websites to request a quote or place an order.

Q: What is the basic process for conducting an experiment with this apparatus?

A: Begin by securing the shaft to the apparatus and setting the desired rotating speed using the power supply. Observations of the shaft's behavior, including deflections and whirling, are then recorded and analyzed to understand critical speed and related phenomena.

Q: How does using this apparatus benefit laboratory teaching and research?

A: Utilizing this apparatus provides hands-on experience for students and researchers, making complex theoretical concepts more accessible and fostering a deeper understanding of mechanical vibrations and shaft dynamics.
