Sterozoom Microscope

18000 INR/Piece

Get a Price/Quote

Product Details:

Spare Parts Spare pairs of eyepieces, objectives, glass stage plate, dust cover, user manual.
Material Mild Steel
Weight 5-10 Kilograms (kg)
Product Type Microscope
Focus System Coarse focusing mechanism with rack and pinion drive.
View Head Binocular head, inclined at 45.
Features Zoom magnification, dual LED illumination, interchangeable eyepieces, robust construction, ergonomic design.
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Sterozoom Microscope Price And Quantity

Minimum Order Quantity 1 Piece
Price 18000 INR/Piece

Application Ideal for schools, colleges, research laboratories, electronics assembly, and quality assurance.
Field of View Wide viewing field up to 20 mm with standard WF10x eyepieces.
Eye Guard Rubber eye guards provided with eyepieces for user comfort.
Accessories Included Dust cover, user manual, pair of eyecups.
Power Supply AC 220V/50Hz or 110V/60Hz with transformer; or rechargeable battery option.
Base Sturdy, heavy duty base for stability during observation.
Head Movement 360° rotation for user convenience.
Packaging Supplied in sturdy carton with fitted thermocol for safe transport.
Color Body finished in epoxy powder coating for durability and easy cleaning.

Sterozoom Microscope Product Specifications

Magnification Zoom range 7x 45x (with 1x objective and 10x eyepieces); expandable with auxiliary objectives and other eyepieces.
Still Image Capture Resolution Dependent on optional camera; not specified for standard unit.
Material Mild Steel
Eyepieces Wide field 10x paired eyepieces (WF10x/20 mm).
Eyepiece Tube Binocular, adjustable for comfortable observation.
Light Source LED lamp, top (incident) and bottom (transmitted).
Drawtube Binocular, 45 inclined, 360 rotatable.
Working Stage Black & white reversible stage plate, 90 mm; stage clips included.
Coarse Adjustment Range 45 mm for focusing head movement.
Focus Range Approx. 45 mm vertical movement of head.
Illumination Incident (top) and transmitted (bottom) LED illumination, adjustable.
Fine Adjustment Range Not available (uses only coarse focus).
Condenser Not included (not required for stereo microscopes).
Spare Parts Spare pairs of eyepieces, objectives, glass stage plate, dust cover, user manual.
Interpupillary Distance Adjustable from 55 mm to 75 mm.
Theory The Sterozoom Microscope is designed for precise and detailed visual inspection and analysis, ideal for biological, industrial, and educational applications.
Frame Rate Not applicable (unless digital camera is attached).
View Head Binocular head, inclined at 45.
Image Format Depends on camera used (if equipped); not applicable for standard optical unit.
Dimensions Approx. 340 mm (H) x 260 mm (W) x 200 mm (D).
Interface Manual (optical viewing); camera port optional for digital interface.
Features Zoom magnification, dual LED illumination, interchangeable eyepieces, robust construction, ergonomic design.
Product Type Microscope
Weight 5-10 Kilograms (kg)
Objective Achromatic Paired achromatic zoom objectives 0.7x to 4.5x.
Video Capture Resolution Dependent on optional camera; not available on standard model.
Sensor Not applicable (optical microscope, sensor not built-in).
Resolution Depends on eyepiece and objective combination; up to 100 lp/mm optical resolution.
Focus System Coarse focusing mechanism with rack and pinion drive.
Focal Distance Working distance typically 80100 mm.

Application Ideal for schools, colleges, research laboratories, electronics assembly, and quality assurance.
Field of View Wide viewing field up to 20 mm with standard WF10x eyepieces.
Eye Guard Rubber eye guards provided with eyepieces for user comfort.
Accessories Included Dust cover, user manual, pair of eyecups.
Power Supply AC 220V/50Hz or 110V/60Hz with transformer; or rechargeable battery option.
Base Sturdy, heavy duty base for stability during observation.
Head Movement 360° rotation for user convenience.
Packaging Supplied in sturdy carton with fitted thermocol for safe transport.
Color Body finished in epoxy powder coating for durability and easy cleaning.

Sterozoom Microscope Trade Information

Payment Terms Telegraphic Transfer (T/T), Cash in Advance (CID), Cheque, Cash Advance (CA)
Supply Ability 7 Piece Per Week
Delivery Time 1 Week
Main Export Market(s) Australia, North America, South America, Eastern Europe, Western Europe, Middle East, Africa, Central America, Asia
Main Domestic Market All India

Product Description

Features & Specification :

Eyepiece :	WF 10X (#22 mm)
Objective :	Zoom range 0.7x -4.2x
Total magnification :	7X-42X
Working distance :	90mm
Illunination :	8W 220V/110V(Fluorecence lamp)
(Accessional objectives) :	0.5X,0.75X,1.5X,2X. (Photo device) :0.4X,1XCCD(adapter
Eye piece field :	Wide & Clear
Base size :	260mm X 290mm
Illumination :	Ttranmitted, reflected and mixed illumination
Objectives range of zoom magnification :	0.7X-4.2X

Versatile Zoom Magnification

The Sterozoom Microscope offers a flexible magnification range from 7x to 45x with standard eyepieces and objectives. This zoom capability is ideal for detailed examinations in both biological and industrial applications, allowing users to observe specimens with clarity and precision. For greater versatility, magnification can be expanded by adding auxiliary objectives or different eyepieces, supporting a broad range of investigative tasks.

Ergonomic and Robust Design

Designed with everyday usability in mind, the microscope's binocular head is inclined at 45 degrees and allows complete 360-degree rotation, providing comfort during prolonged observation sessions. The sturdy, powder-coated metal base ensures stability, while easy-to-clean surfaces and rubber eye guards support hygienic and comfortable usage even in high-traffic educational and laboratory environments.

Efficient Illumination and Power Options

Dual LED lighting - incident (top) and transmitted (bottom) - ensures uniform illumination suitable for opaque and transparent specimens. The microscope operates with AC voltages of 220V/50Hz or 110V/60Hz via transformer, or with a rechargeable battery for field mobility, granting flexibility across diverse working environments.

FAQ's of Sterozoom Microscope:

Q: How does the Sterozoom Microscope achieve precise focusing?

A: The Sterozoom Microscope uses a coarse focusing mechanism driven by a rack and pinion system, providing approximately 45 mm vertical head movement. This allows for easy and swift adjustments, ensuring sharp images during routine viewing and specimen switching.

Q: What is the typical process for setting up the Sterozoom Microscope?

A: Setup involves unpacking the microscope from its carton with fitted thermocol, attaching the paired WF10x eyepieces, connecting the power supply or installing the battery, and placing the included dust cover and eye guards. Once assembled, the illumination and zoom can be adjusted as needed for optimal viewing.

Q: When is this microscope most beneficial for users?

A: This microscope is most beneficial during applications requiring detailed, three-dimensional inspection, such as in research labs, quality assurance departments, educational settings, and electronics assembly, thanks to its wide field of view, ergonomic design, and robust construction.

Q: Where can the Sterozoom Microscope be effectively used?

A: The microscope is ideal for classrooms, research laboratories, quality control environments, and electronics workshops. Its portability with rechargeable battery options also allows field use where conventional power sources are unavailable.

Q: What accessories and spare parts are included or available?

A: The Sterozoom Microscope comes supplied with a dust cover, user manual, and pair of eyecups. Spare accessories such as additional eyepieces, paired objectives, glass stage plates, and dust covers are available from the manufacturer or distributor for future needs.

Q: How do users benefit from the microscope's dual LED illumination?

A: Dual LED illumination provides both incident (top) and transmitted (bottom) lighting options, which are independently adjustable. This enables users to observe a wide variety of specimens, from opaque solids to translucent or transparent biological samples, ensuring versatile and accurate results.
