AUTOMOBILE OSCILLOSCOPE

40000 INR/Piece

Get a Price/Quote

Product Details:

Features Multi-channel Input, High Sampling Rate, Portable, Data Logging, USB Interface
Accuracy High Precision, 1%
Display Type Digital LCD
Shape Rectangular
Control Type Digital
Power Supply DC Power Adapter / Battery
Temperature Resistance -10C to 50C
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

AUTOMOBILE OSCILLOSCOPE Price And Quantity

Price 40000 INR/Piece
Minimum Order Quantity 1 Piece

Probe 2 x Oscilloscope Probe Included
Input Channels 2
Weight 1.2 Kg
Memory Depth 10 Kpts
Trigger Modes Edge, Pulse, Video
Bandwidth 20 MHz
Battery Backup Built-in Rechargeable Battery
Sampling Rate 100 MS/s
Connectivity USB, PC Software Support

AUTOMOBILE OSCILLOSCOPE Product Specifications

Control Type Digital
Power Supply DC Power Adapter / Battery
Temperature Resistance -10C to 50C
Power 10 W
Weight 1000-1500 Grams (g)
Equipment Type Handheld Diagnostic Tool
Material Metal
Application For Hospital
Equipment Materials ABS Plastic, High-Grade Electronics
Accuracy High Precision, 1%
Display Type Digital LCD
Shape Rectangular
Type Automobile Oscilloscope
Features Multi-channel Input, High Sampling Rate, Portable, Data Logging, USB Interface
Product Type AUTOMOBILE OSCILLOSCOPE
Dimension (L*W*H) 32 cm x 22 cm x 8 cm
Voltage 12-24 Volt (v)

Probe 2 x Oscilloscope Probe Included
Input Channels 2
Weight 1.2 Kg
Memory Depth 10 Kpts
Trigger Modes Edge, Pulse, Video
Bandwidth 20 MHz
Battery Backup Built-in Rechargeable Battery
Sampling Rate 100 MS/s
Connectivity USB, PC Software Support

AUTOMOBILE OSCILLOSCOPE Trade Information

Payment Terms Telegraphic Transfer (T/T), Cash in Advance (CID), Cheque, Cash Advance (CA)
Supply Ability 1 Piece Per Day
Delivery Time 1 Week
Main Export Market(s) Australia, South America, Eastern Europe, Western Europe, Middle East, Asia, Central America, North America, Africa
Main Domestic Market All India

Product Description

AUTOMOBILE OSCILLOSCOPE

Description:
Dual-track oscilloscope can directly test the signal waveforms and data, AC and DC voltage, frequency, Pulse-Width and duty cycle.
There are six testing channels that can test the secondary ignition of the six cylinders at the same time.
Functions of digital meter.
Intelligent testing functions no need set up data by manual work, test components at a high speed.
Details:

Signal Input
Input Impedance	10M
Input Voltage	-1000V ~ +1000V
Digital Meter
Frequency(Hz)	0Hz ~50KHz
Duty Cycle	0.1%~99.9%
Ignition Test
RPM	0-3000RPM(Two Stroke) /0-6000RPM(Four Stroke)
Ignition Channel	6
Config
ROM	32MB
RAM	4MB
Connect With PC	RS232 115200bps
Working Characteristics
Power Input	3.3V-5V
Power down Current	15mA -25mA

Dual Channel High-Performance Diagnostics

With two input channels and a 20 MHz bandwidth, this automobile oscilloscope enables the simultaneous monitoring of multiple automotive electronic signals. Its high sampling rate of 100 MS/s provides crisp waveforms, assisting technicians in identifying irregularities swiftly and accurately.

Portability and Rugged Design

Crafted from ABS plastic and high-grade electronics, this oscilloscope is lightweight yet robust, weighing between 1000-1500 grams. The integrated rechargeable battery and compact rectangular shape ensure easy transport and operation, even in demanding environments.

Versatile Triggering & Data Management

Featuring edge, pulse, and video trigger modes, the oscilloscope accommodates a variety of diagnostic needs. It simplifies data management with USB connectivity, digital LCD display, and PC software support, making analysis and data logging effortless for users.

FAQ's of AUTOMOBILE OSCILLOSCOPE:

Q: How do I operate the automobile oscilloscope for diagnostic tasks?

A: To use the oscilloscope, connect the provided probes to the desired test points in your vehicle's system, power on the device using the built-in battery or DC adapter, and configure the trigger mode (Edge, Pulse, or Video). The digital LCD display will show real-time signal waveforms, allowing for immediate analysis.

Q: What application areas are suitable for this automobile oscilloscope?

A: This oscilloscope is designed for automotive diagnostics, making it ideal for use in workshops, hospitals, and field service operations. Its versatility allows it to analyze sensors, actuators, and communication lines in vehicles with 12-24 Volt electrical systems.

Q: When should I use the edge, pulse, or video trigger modes?

A: Edge trigger mode is best for capturing signal transitions, pulse trigger is ideal for timing-specific events, and video trigger is used for analyzing video signals or patterns. Select the appropriate trigger to align with your diagnostic need for precise results.

Q: Where can I store and analyze the captured data?

A: Captured waveform data can be stored via the USB interface and analyzed using the supplied PC software. This enables more comprehensive reviews and comparisons of diagnostic results on a computer, facilitating accurate troubleshooting.

Q: What are the benefits of the handheld design and built-in battery?

A: The handheld, portable design coupled with a built-in rechargeable battery allows technicians to perform diagnostics without being tethered to a power outlet. This enhances flexibility and convenience, especially in remote locations or on-site service calls.

Q: How accurate are the measurements from this oscilloscope?

A: The device boasts high precision with a measurement accuracy of 1%, ensuring reliable diagnostics and minimizing the risk of misinterpretation in automotive signal analysis.

Q: What is the process for maintaining this oscilloscope?

A: To maintain optimal performance, store the oscilloscope in a dry, dust-free environment, recharge the battery regularly, and periodically inspect the probes and connectors for wear. Clean the exterior with a soft, damp cloth and avoid exposure to extreme temperatures beyond its rated range.
