Surgical Microscope Direct Halogen

Surgical Microscope Direct Halogen
Surgical Microscope Direct Halogen
Send Inquiry
Product Code : 02
Brand Name : Ajanta
Product Description

Surgical Microscope Direct Halogen

Surgical Microscope Direct Halogen is also same as Surgical Microscope Cold Light but with the difference that the additional illuminating beam Halogen Lamp and a measurement beam which makes the patients surgery very clear.

Specifications

Microscope Section

Binocular Tube : 90° ENT & General Surgery

Eyepieces : 12.5x/ 10x/ 16mm Dioptric Adjustment

Magnification Changes : Built in Manual 3-Step Changer

Total Magnification : 7.5x, 12.5x, 20x

Field of View : 59mm, 37.8mm, 23.5mm, 14.5mm, 9.5mm

Objective Lens : F = 200, 250, 300, 400mm (For General Micro-Surgical Fields)

Working Distance : 200mm

Interpupillary Distance Adjustment : 55mm to 75mm

Illumination Section

Type : Direct Halogen

Light Source : 12V/50Watts Halogen lamp

Illumination Control : Continuous Adjustment

Field of illumination : 70mm

Filter : Cobalt Blue, Red Free, Heat Absorbing

Stand Section

Type : Table Clamp

Vertical Movement Of Counterbalanced Arm : 400 mm

General Information

Weight : 50Kg.

Height : 1550mm

Electrical Power : AC 220V, 240V, 50/60 Hz

Power Consumption : 220 VA/110V

Optional Accessories

Beam Splitter With CCD Camera Attachment

CCD Camera

Optional accessories are listed as separate items in "Accessories" section under products, there brought separately.
