Stability Test Chamber

Stability Test Chamber solutions offered by us are precision designed and developed so as to provide quality solutions for stability testing of complete range of components, materials as well as systems manufactured including assemblies. Other than this, these stability test chambers also assist in providing solutions for storage of laboratory test samples and testing of material samples. With the stability test chambers supplied in a range of sizes, these meet a range of requirements. The system also comes with features like high energy efficiency, compact, proven technology, wide voltage range and ozone friendly refrigerants.

These stability tests are also important step in developing new drugs and pharmaceutical substances and form indispensable element in licensing process as defined by federal regulating authorities. Further, these tests are important for safeguarding quality of product within framework of defined quality standards. The test chambers also have provision of collecting the data in printed format from up to eight different points that include six temperature points and two humidity points present within chamber.

Construction:

• Double walled unit having inner chamber made of anodized Aluminum or S.S.
• Outer chamber made of M.S. Sheet that is duly painted
• Supplied complete with 14 adjustable perforated trays
• Complete with cord and plug to work on 220/230 V A.C. Supply

Temperature:

• Micro processor based INDICATOR -cum-CONTROLLER for controlling temperature from 5°C to 50°C + 1°C

Humidity:

• Humidity created in S.S. Water reservoir fitted at bottom so as to provide 90% to 95% + 3% RH Humidity

Technical Specifications:

SIZES(W x D x H)	CAP. APPROX	CAP
570 x 875 x 550 mm	10 cu. ft.	280 Ltrs
775 x 900 x 775 mm	20 cu. ft.	560 Ltrs
835 x 1200 x 825 mm	30 cu. ft.	840 Ltrs
900 x 1720 x 800 mm	45.8 cu. ft.	1282 Ltrs
