Laboratory Hot Air Oven 12*12
15000 INR/Piece
Product Details:
- Type Laboratory Hot Air Oven
- Chamber Size 12 x 12 x 12 inches
- Chamber Thickness 1.2 mm SS 304 Grade
- Outer Size 17 x 17 x 22 inches (approx.)
- Compressed Air Required for operation
- Door Type Double Wall Insulated Hinged Door
- Design Pressure Atmospheric
- Click to View more
X
Laboratory Hot Air Oven 12*12 Price And Quantity
- 1 , , Piece
- 15000 INR/Piece
Laboratory Hot Air Oven 12*12 Product Specifications
- Uniform Air Circulation (Forced-air type)
- Up to 250C
- Approx. 45 kg
- Laboratory Hot Air Oven
- Digital Temperature Controller & Indicator
- Double Wall Insulated Hinged Door
- High-grade Glass Wool Insulation
- Ambient to 250C
- 17 x 17 x 22 inches (approx.)
- Atmospheric
- Heavy-Duty SS Piping System
- 12 x 12 x 12 inches
- Stainless Steel Piping
- Air Vent Valve Provided
- Atmospheric
- Up to 250C
- Approx. 2.6 kW
- Required for operation
- 1.2 mm SS 304 Grade
Product Description
Laborotary Ovens are convention appliances for general purpose in the scientific and manufacturing industries. Applications include sterilization, experiment management drying processing and testing.
Technical Specification
| Brand | AjantaExport |
| Model Name/Number | AEI-sh-13 |
| Temperature Range | 50-250 Degree Celsius |
| Material | Stainless Steel |
| Chamber Volume | 65 Litre |
| Warranty | 1 year |
| Country of Origin | Made in India |
Inner Size Capacity Wattage
12''x12''x12'' 28 litres 750
14'''x14''x14'' 45 litres 1000
16'''x16''x16'' 65 litres 1200
18''x18''x18'' 95 litres 1500
24''x18''x18'' 125 litres 2000
24''x24''x24'' 228 litres 2500
36''x24''x18'' 252 litres 3000
36''x24''x24'' 342 litres 3000
36''x36''x36'' 720 litres 4500
OPTIONAL FOR LABORATORY HOT AIROVEN
Please add extra for the following options:
a) Digital PID Controller indicator cum controller.
b) Air Circulation Fan.
c) Timer 0-24 Hours.
d) Digital Temp. indicator.
e) PID Digital Temp. Controller with timer.
Advanced Temperature Control
The oven utilizes a digital PID controller and LED display for precise temperature regulation. Users can easily set their desired temperature and timer, ensuring consistent and reliable results. Over-temperature protection and automatic shut-off offer added safety during operation.
Durable & Easy to Maintain
Constructed with a stainless steel inner chamber and trays, the oven is resistant to corrosion and easy to clean. The external mild steel chamber with epoxy powder coating provides toughness and a sleek finish, suitable for demanding laboratory conditions.
Uniform Heating Performance
A strong air circulating fan distributes heat evenly throughout the chamber, supported by high-grade glass wool insulation. This guarantees uniform temperature, which is essential for effective drying, baking, and sterilizing of laboratory materials.
FAQ's of Laboratory Hot Air Oven 12*12:
Q: How does the Laboratory Hot Air Oven 12*12 ensure uniform heating?
A: Uniform heating is achieved by a powerful air circulating fan, combined with forced-air design and high-grade glass wool insulation. These features help distribute hot air evenly within the chamber, ensuring consistent results for all samples.Q: What safety features are included in this hot air oven?
A: The oven is equipped with over-temperature protection and automatic shut-off mechanisms to prevent overheating. The silicon rubber gasket and double-wall insulated door further ensure safe, leak-proof operation during use.Q: When should the Laboratory Hot Air Oven be calibrated or serviced?
A: The oven comes factory calibrated and certified, making it ready for use upon installation. It is recommended to schedule periodic checks aligned with laboratory protocols, especially before critical processes, to maintain accuracy and efficiency.Q: Where is this oven most suitable for use?
A: This oven is ideal for laboratory settings, including research institutions, universities, and industrial quality control laboratories. It is designed for applications such as drying, baking, and sterilization of samples and equipment.Q: What process controls and settings are available?
A: Users can adjust the oven's temperature up to 250C and set the timer for up to 999 minutes using the digital PID controller. The LED display provides real-time temperature readings, allowing for precise management of process parameters.Q: How do you benefit from the adjustable stainless steel shelves?
A: Having two adjustable solid stainless steel shelves allows you to customize internal spacing, enabling effective accommodation of various sizes and quantities of laboratory items, thus enhancing workflow flexibility and efficiency.Q: What materials are used in the oven's construction for durability?
A: The oven features an inner chamber and trays constructed from corrosion-resistant stainless steel, while the outer chamber is made of durable mild steel, finished with epoxy powder coating for extended longevity and protection.Tell us about your requirement
