DIESEL -ELECTRIC ENGINES TEST BED

Name: DIESEL -ELECTRIC ENGINES TEST BED
Brand: AJANTA EXPORT INDUSTRIES
Price: 25000 INR
Availability: InStock

25000 INR/Piece

Get a Price/Quote

Product Details:

Display Type Digital Display
Features Integrated Measuring Instruments, Safety Enclosures, Heavy Duty Construction, Water Cooled System
Temperature Resistance Up to 120°C
Shape Rectangular
Control Type Digital Control Panel
Power Supply Electric
Accuracy ±0.5%
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

DIESEL -ELECTRIC ENGINES TEST BED Price And Quantity

Price 25000 INR/Piece
Minimum Order Quantity 1 Piece

DIESEL -ELECTRIC ENGINES TEST BED Product Specifications

Control Type Digital Control Panel
Equipment Type Engine Testing Bench
Dimension (L*W*H) 2200 mm x 1200 mm x 1800 mm
Usage For Hospital
Application Testing Diesel and Electric Engine Performance
Temperature Resistance Up to 120°C
Shape Rectangular
Voltage 240 Volt (v)
Type Diesel-Electric Engines Test Bed
Capacity (Ltr) 50 Liters (Cooling System)
Display Type Digital Display
Features Integrated Measuring Instruments, Safety Enclosures, Heavy Duty Construction, Water Cooled System
Material Mild Steel
Equipment Materials Mild Steel Frame, Stainless Steel Components
Speed Range Up to 4000 RPM
Accuracy ±0.5%
Product Type ENGINES TEST BED
Power Supply Electric
Power 3 kW

Ambient Operating Temperature 5°C to 40°C
Mobility Mounted on Castor Wheels
Safety Features Emergency Stop, Overload Protection
Instrument Panel Multi-parameter Digital Panel with Indicator Lights
Data Acquisition Optional PC Connectivity and Data Logging
Measurement Parameters Torque, RPM, Power Output, Fuel Consumption
Chassis Heavy-Duty Reinforced Platform
Engine Types Supported Single Cylinder, Double Cylinder
Engine Mounts Adjustable, Anti-Vibration Pads
Starter System Electric Start
Cooling System Water Cooled, Circulating Pump
Noise Level Below 75 dB
Fuel Tank Capacity 25 Liters
Paint Finish Anti-Corrosive Industrial Paint

DIESEL -ELECTRIC ENGINES TEST BED Trade Information

Payment Terms Telegraphic Transfer (T/T), Cash in Advance (CID), Cheque, Cash Advance (CA)
Supply Ability 7 Piece Per Day
Delivery Time 1 Week
Main Export Market(s) Western Europe, Australia, North America, Eastern Europe, Middle East, Central America, South America, Asia, Africa
Main Domestic Market All India

Product Description

DIESEL -ELECTRIC ENGINES TEST BED

Description:
Teaching Function: It can completely show the structure and working principle of diesel-electric engine to help students understand abstract theory. It can imitate, diagnose and test the common faults and troubles of diesel-electric engine. Train students to analyze and solve practical problems. Extend items: Multimedia network teaching, the establishment of specialized teaching and learning environment, and standardized evaluationsystem.
Details:

Standard Configuration:

It can adopt the diesel-electric engine designated by customers. The rack is divided into two parts, one the main body rack, the other test table. The main body can operate independently, and also can be used with the test table.

Set up electric circuit abruption and rosin joint of electronic control system by hand or remote. There are two breakdown modes for choice: teaching and practical training.

Diagnose connections are configured to connect testing equipment special for motor vehicles.

Extend Configuration

Test-bed and PC carry on real-time communication. The computer monitor can display work status of all sensors and actuators of electronic control system. You can set up electric circuit abruption and rosin joint of electronic control system through computers.

Configuration of multi-media network teaching and learning environment that uses a multi-board manner, each student configures information display device, the main components terminal voltage detection device and information input device, so that students learn to analyze and solve practical problems under teachers' leadership;

Standardized evaluation system, print out students' achievement lists.

Precision Engine Testing Made Easy

The Diesel-Electric Engines Test Bed offers a reliable solution for engine performance assessments. Its integrated digital control panel and measuring instruments make handling key parameters such as torque, RPM, and fuel consumption straightforward. Built for professional laboratories, it provides a stable testing environment with impressive noise control and safety features.

Heavy-Duty Construction for Lasting Performance

Engineered with a durable mild steel frame and stainless steel components, this test bed is built for longevity. The robust materials and anti-corrosive industrial paint protect against wear and harsh laboratory settings, while adjustable engine mounts and anti-vibration pads secure diverse engine types during operation.

Advanced Safety Features and Easy Operation

Equipped with emergency stop and overload protection, the test bed ensures secure testing routines. The intuitive multi-parameter digital instrument panel enables precise monitoring, while safety enclosures shield operators throughout the process. Quick mobility is achieved with castor wheels, ideal for dynamic lab environments.

FAQ's of DIESEL -ELECTRIC ENGINES TEST BED:

Q: How does the Diesel-Electric Engines Test Bed measure engine performance?

A: The test bed uses a multi-parameter digital panel to capture essential metrics such as torque, RPM, power output, and fuel consumption, ensuring precise assessments during engine testing.

Q: What types of engines are supported by this testing bench?

A: This test bed supports both single-cylinder and double-cylinder engines, making it versatile for various testing applications in hospitals, research labs, and industrial settings.

Q: When should I use the emergency stop and overload protection features?

A: Emergency stop and overload protection should be activated in any situation where unexpected operational issues arise or if the system detects unsafe parameter thresholds, ensuring immediate shutdown and operator safety.

Q: Where can I install or use the Diesel-Electric Engines Test Bed?

A: The unit is suitable for indoor environments where ambient temperatures range between 5C and 40C, such as research labs, hospitals, or industrial workshops, and its castor wheels allow easy relocation.

Q: What is the process for data acquisition and logging during testing?

A: The test bed provides optional PC connectivity for real-time data acquisition and logging. Collected data on engine performance can be monitored, recorded, and analyzed through dedicated software for comprehensive evaluations.

Q: What are the benefits of the water-cooled system and circulating pump?

A: The water-cooled system, featuring a 50-liter capacity and circulating pump, maintains optimal engine temperatures up to 120C, resulting in more consistent engine performance and increased testing accuracy.

Q: How accurate are the measurements provided by the test bed?

A: The Diesel-Electric Engines Test Bed delivers measurement accuracy within 0.5%, ensuring reliable and trustworthy data for all recorded engine parameters.
