Binocular Microscope Co- Axil Stage

5500 INR/Unit

Get a Price/Quote

Product Details:

Weight 3-8 Kilograms (kg)
Application For Laboratory
Product Type Microscope
Material Steel
Operate Method Manual
Drawtube Binocular
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Binocular Microscope Co- Axil Stage Price And Quantity

Price 5500 INR/Unit
Minimum Order Quantity 1 Unit

Binocular Microscope Co- Axil Stage Product Specifications

Application For Laboratory
Weight 3-8 Kilograms (kg)
Product Type Microscope
Drawtube Binocular
Material Steel
Operate Method Manual

Binocular Microscope Co- Axil Stage Trade Information

FOB Port AMBALA CANTT
Payment Terms Telegraphic Transfer (T/T), Cash in Advance (CID), Cheque, Cash Advance (CA)
Supply Ability 7 Unit Per Week
Delivery Time 1 Week
Sample Available No
Main Export Market(s) Western Europe, Australia, Eastern Europe, Middle East, Africa, South America, Asia, Central America, North America
Main Domestic Market All India
Certifications ISO 9001:2015 , CE

Product Description

Details

Model	AEI/BMC/57
Observation head	Binocular observation head inclined at 45 degree, rotateable through 360 degree, inter pupilary distance adjustment ring 54-74 mm & dioptric adjustment.
Main body	All part pressure die cast to provide long life and good mechanical strength.
Eye pieces	Wide field 10x or 15x paired
Objectives	4x,10x,40/45x (s. L. ), 100x oil immersion (s. L. )
Nose pieces	Quadruple no sepiece revolves on ball bearing
Mechanical stage	Co-axial low positioned mechanical x-y stage of size 120 x 125 mm with stage fine vernier graduation
Condenser	Abbe condenser n. A. 1. 25 having a spherical lens, adjustable iris diaphragm.
Illumination	Built in base illumination system with 6v-20w halogen bulb and plano concave mirror attachment suitable for 220v, 50hz ac supply
Packing	Nicely packed in box.

Precision and Comfort Combined

This binocular microscope boasts a co-axial stage, enabling precise movement of slides for detailed specimen analysis. Its ergonomic binocular design ensures comfort during extended laboratory sessions, reducing eye fatigue and providing a clearer, three-dimensional view. The manual operation makes it intuitive for users of varying experience levels.

Built for Laboratory Excellence

Crafted from sturdy steel, the microscope provides longevity and stability, essential for daily laboratory use. Its weight range of 3 to 8 kilograms ensures easy relocation without compromising on durability, making it suitable for both stationary and mobile lab environments. The product is reliable whether used in schools, diagnostics labs, or research institutes.

FAQ's of Binocular Microscope Co- Axil Stage:

Q: How is the Binocular Microscope with Co-Axial Stage used in laboratory settings?

A: This microscope is designed for manual operation with a co-axial stage, allowing precise movement of specimens across the viewing area. Users can comfortably view samples through the binocular drawtube, making it ideal for detailed analysis in laboratories.

Q: What materials are used in manufacturing the Binocular Microscope Co-Axial Stage?

A: The microscope is constructed from high-quality steel, ensuring durability, strength, and long-term performance suitable for extensive laboratory use.

Q: When is it beneficial to use a binocular microscope with a co-axial stage over other types?

A: A binocular microscope with a co-axial stage is particularly advantageous when frequent and precise adjustments of specimen position are required, such as in research, diagnosis, or educational demonstrations.

Q: Where can this microscope be purchased or supplied in India?

A: This product is available through distributors, exporters, manufacturers, suppliers, and traders throughout India, making it accessible for laboratories nationwide.

Q: What is the process for operating the manual stage on this microscope?

A: To operate the manual co-axial stage, users adjust the stage knobs to smoothly move slides horizontally or vertically, enabling fine-tuned positioning for optimal specimen examination.

Q: What are the benefits of the binocular drawtube feature?

A: The binocular drawtube allows for comfortable, extended viewing by distributing the visual workload to both eyes. This reduces eye strain and enhances clarity, supporting more efficient and accurate observations.
